WEALDEN TOOL
NEW PRODUCTS Quality products - quality service
COM PAN Y
C
BUTT BEAD

These bearing guided two flute cutters will produce a bead D
and V profile for bead and butt boarding.
Price
Part No. A B C D E F inc. VAT
T2690B–8 6.0mm 19.6mm 8mm 38mm 19.2mm 3.6mm £20.40 B
T2693B–8 8.0mm 22.6mm 8mm 38mm 21.2mm 4.6mm £22.44 A
T2696B–8 10.0mm 25.6mm 8mm 38mm 23.2mm 5.6mm £25.80
T2697B 1/2 10.0mm 25.6mm 1/2" 40mm 23.2mm 5.6mm £25.80
F E

C
BLENDING RADIUS

Two flute TC tipped cutters with flat bottom and
radiused corners to enable smoother transitions
between tool paths on three dimensional profiles.
D

Price
Part No. A B C D E inc. VAT
T2961 – 8 6.0mm 10.0mm 8mm 50mm 1.5mm £15.54
T2963 – 8 8.0mm 10.0mm 8mm 50mm 2.0mm £15.54 B
T2965 – 8 10.0mm 10.0mm 8mm 50mm 3.0mm £15.54
E
A radius

ESPAGNOLETTE GROOVE VERTICAL C

A cutter to cut the faceplate rebate and clearance for the
mechanism for a 16mm nominal espagnolette locking system. D
This type of cutter will profile vertically when the traditional
horizontal cutter cannot be used.
Price
Part No. A B C D E F inc. VAT B
T4420–8 16.2mm 10mm 8mm 38mm 12mm 10mm £19.50
T4420 1/2 16.2mm 10mm 1/2" 40mm 12mm 10mm £19.50 F
E
A

NEW SIZES IN EXISTING RANGES

PRODUCT PART No. PAGE DESCRIPTION PRICE inc. VAT
Panel trim T8048B 1/2 35 Same as T8020B-1/2 but length "B" is 65mm £32.70
Ovolo – round over T1340E 1/2 19 Same as T1340-1/2 but radius" A" is 15mm £32.40
Straight two flute TL212M 3 Same as T212M but shank length "D" is 50mm £11.20
Straight two flute TL1112M 3 Same as T1112M but shank length "D" is 55mm £11.30
Straight two flute T1416.5M 4 Same as T1416MM but diameter "A" is16.5mm £18.72
Beaded edge T2509B-8 42 Same as T2503B-8 but diameter "A" is 8mm £29.52

Orderline 01580 890500 8 Fax orders 01580 890222
